This article describes the proper flashing details for exterior doors to avoid air leaks, rot, decay, and energy losses at doors. In this article series we discuss the selection and installation of windows and doors, following best construction and design practices for building lighting and ventilation, with attention to the impact on building heating and cooling costs, indoor air quality, and comfort of occupants. We review the proper installation details for windows and doors, and we compare the durability of different window and door materials and types.

Guide to Exterior Door Flashing Details

As detailed in Best Practices Guide to Residential Construction Chapter 3, BEST PRACTICES GUIDE: WINDOWS & DOORS:

Doors are flashed the same as windows on the sides and top, and similarly at the sill. Clad door frames are flashed like clad windows (see our window flashing illustrations below, Figures 3-13, Figure 3-15, Figure 3-16) and solid wood frames are flashed like traditional windows with brickmold (Figures 3-17 also below).

Figure 3-13: Installing Flange-type WIndows Over House-Wrap

Figure 3-15: Installing Flange-type Windows Before the House Wrap is Applied

Figure 3-16: Installing Flange-type Windows with Felt Paper

This article includes excerpts or adaptations from Best Practices Guide to Residential Construction, by Steven Bliss, courtesy of Wiley & Sons.

See WINDOWS & DOORS our home page for window and door information, and also see WINDOW TYPES - Photo Guide for a photographic guide to window and door types and architectural styles.

Figure 3-17: Installing Windows with Brickmold Trim

Unless a door is well-protected by a porch or large overhang, good pan flashing at the sill is critical to prevent water from seeping into the floor framing. Doors leading to patios and decks are particularly vulnerable to wetting around the sill from splashback and, in cold climates, from snow buildup.

Pan Flashing for Exterior Doors

Prefab plastic door pans typically come in three sections that are fused together at the required length with solvent-based cement. Metal pans require a brake to form and should be caulked or, preferably, soldered at corners.

In fact the absence of effective flashing at this 20-year-old sliding glass door led to the need for a complete door, door jamb, and trim replacement on this Poughkeepsie home. When the new door was installed we included a sit-built pan flashing and membrane flashing around the door for a more durable replacement.

Peel-and-stick membranes have become increasingly popular due to their ease of use and flexibility. Whether to use a metal pan, plastic pan, or peel-and stick membranes is a matter of personal preference as all work well (see Figure 3-26 below).

Figure 3-26

Figure 3-27

Whatever material is used, all pans should have a dam on the ends and along the inside edge. On the exterior, the pan flashing should lap over the deck or masonry flashing below. If forming a pan with peel-and-stick membrane, carry it up the sides at least 6 inches, and turn up the inside edge so it is held in place by the underlayment or finish flooring (Figure 3-27 above).

Also see
WINDOW / DOOR AIR LEAK SEALING HOW TO
WINDOW LEAKS INTO BASEMENT

Window and Door Resources: where to buy window and door products

As noted in Best Practices Guide to Residential Construction Chapter 3, BEST PRACTICES GUIDE: WINDOWS & DOORS:

Manufacturers of Windows & Doors

Windows and Patio Doors

Andersen Windows and Doors www.andersenwindows.com Vinyl-clad windows and patio doors, including storm resistant models

Atrium Companies Inc. www.atriumcompanies.com Vinyl and aluminum windows and patio doors

Certainteed Corp. www.certainteed.com Vinyl windows and patio doors

Crestline Windows and Doors www.crestlinewindows.com Wood, vinyl, and aluminum-clad windows and patio doors

Eagle Windows and Doors www.eaglewindow.com Extruded-aluminum-clad windows and sliders with LVL frames and steel entry doors

Fibertec Windows and Door Manufacturing www.fibertec.com Pultruded fiberglass windows and doors

Hurd Windows and Doors www.hurd.com Wood, vinyl, and aluminum clad windows and patio doors

Jeld-Wen Windows and Doors www.jeld-wen.com Wood, vinyl, aluminum-clad, and aluminum windows and patio doors

Kolbe Windows and Doors www.kolbe-kolbe.com Wood, vinyl, and aluminum-clad windows and patio doors

Marvin Window and Doors www.marvin.com Wood and extruded-aluminum-clad windows and patio doors, including true divided lites and storm-resistant models

Milgard Windows and Doors www.milgard.com Wood, aluminum, vinyl, and fiberglass-clad windows and patio doors

MW Windows www.mwwindows.com Wood, vinyl, and vinyl-clad windows and patio doors

Peachtree Doors and Windows www.peach99.com Vinyl-clad and aluminum-clad windows with optional hardwood interior; aluminum-clad, steel, and fiberglass patio doors with optional hardwood interior

Pella Windows and Doors www.pella.com Wood and aluminum-clad windows and patio doors with optional between-the-glass shades and blinds, including storm-resistant models

Thermotech Windows Ltd. www.thermotechwindows.com Complete line of fiberglass pultruded windows

Weather Shield Windows and Doors www.weathershield.com Wood, vinyl, vinyl-clad, and aluminum-clad windows and patio doors, including historic replacement windows and storm-resistant models

WindsorWindows and Doors www.windsorwindows.com Wood and vinyl windows and patio doors, including a line of wood windows with a cellular-PVC exterior

Door Manufacturers & Products Guide

Benchmark Entry Systems (division of Therma-Tru Doors) www.benchmarkdoors.com Steel and fiberglass entry doors

Jeld-Wen Windows and Doors www.jeld-wen.com Wood, wood composite wood, fiberglass, and steel entry doors

Kolbe Windows and Doors www.kolbe-kolbe.com Wood, steel, and fiberglass entry doors with LVL core and optional extruded-aluminum cladding on frame

Lamson-Taylor Custom Doors and Millwork www.lamsontaylor.com Custom pine and hardwood entry doors with foam insulation core

Masonite Corp. www.masonite.com Steel, wood-edged steel, and fiberglass entry doors

Peachtree Doors and Windows www.peach99.com Steel and smooth and textured fiberglass entry doors

Pella Windows and Doors www.pella.com Fiberglass and steel entry doors

Phoenix Door Manufacturing Company www.phoenixdoor.com Softwood and hardwood entry doors up to 8 ft. high and custom designs

Simpson Door Company www.simpsondoor.com Douglas-fir, hemlock, oak, and mahogany entrance doors, including custom doors; also primed MDF, particleboard, and composite wood doors

Stanley Door Systems (division of Masonite) www.stanleyworks.com Steel and fiberglass entry doors

Weathershield Windows and Doors www.weathershield.com Wood and steel entry doors, with wood, vinyl, aluminumclad, and vinyl-clad frames

Taylor Building Products www.taylordoor.com Steel (stainable finish) and fiberglass entry doors

Therma-Tru Doors www.thermatru.com Steel and fiberglass entry doors with optional vinyl-clad jambs

Industry Associations for Windows & Doors

American Architectural Manufacturers Association (AAMA) www.aamanet.org

Efficient Windows Collaborative www.efficientwindows.org

National Fenestration Rating Council (NFRC) www.nfrc.org Sustainable by Design www.susdesign.com

Shareware calculators for sun angles, solar heat gain, and shading

Window and Door Manufacturers Association (WDMA) www.wdma.com

-- Adapted and paraphrased, edited, and supplemented, with permission from Best Practices Guide to Residential Construction.
