Here we discuss methods and materials used to control sound transmission in or through building floors. This article includes excerpts or adaptations from Best Practices Guide to Residential Construction, by Steven Bliss, courtesy of Wiley & Sons. The page top photo shows floor re-framining in process in an older building where no sound control details had been applied. Details of floor soundproofing designs are given below.

© Copyright 2009 Daniel Friedman, Steve Bliss, Wiley & Sons, All Rights Reserved. Information Accuracy & Bias Pledge is at below-left. Use links at the left of each page to navigate this document or to view other topics at this website. Green links show where you are in our document or website.

Sound Control Methods for Building Floors

The sound transmission class (STC) rating of a floor measures only the reduction in airborne sound transmission. A floor, however, also transmits structure-borne sound, such as footsteps or a slammed door, directly through the materials.

The ability to reduce impact sound is rated by the Impact Isolation Class (IIC) rating.

The most cost-effective technique to reduce impact noise is to add a carpet and pad.

For example, adding a carpet and pad to a conventional plywood subfloor over a gypsum ceiling increases the IIC rating from 37 to 65. By comparison, it increases the STC rating by only 4 points.

Where higher STC and IIC ratings are needed, a resilient channel can be added to the ceiling below.

Where this is not possible, for example when the joists are exposed below, you can use a floating floor over a layer of soundboard or a high-mass floor over a layer of sand or lightweight concrete.

See our Table of STC and IIC ratings for Typical Wall/Ceiling Assemblies - also shown in part at the top of this article.

IIC levels are of greatest concern in stacked multifamily dwellings or in a single-family dwelling with bedrooms below other living spaces.

Acoustical experts recommend a minimum IIC rating of 50 to 55 in ceiling/floor construction, separating living units in multifamily construction.

HUD recommendations for bedrooms under living spaces are shown in our Table of Minimum Sound Insulation for Ceiling/Floor Assemblies Above Bedrooms.

While these recommendations were developed for multifamily dwellings, they provide reasonable targets for single-family homes where sound privacy is desired.

-- Adapted with permission from Best Practices Guide to Residential Construction.
