Light-Transmitting, Heat-Reflecting Films: Should I Use on Solar Collectors?

• Q&A on use of Heat Mirror™ or 3-M Scotchtint™ on Solar Collectors- original text. Use your browser's back button to return to this page

The question-and-answer article about the indoor use of heat-reflecting window films to increase the efficiency of a solar collector, quotes-from, updates, and comments an original article, (see links just above) from Solar Age Magazine and written by Steven Bliss.

Question: Could low-transmission films such as 3M's Scotchtint™ or Heat Mirror™ be used to increase the efficiency of Solar Collectors?

I have heard a lot about light-transmitting, heat-reflecting widow films, such as Heat Mirror™ and 3-M's Scotchtint™. These would seem to be ideal materials for use in solar collector glazings to reduce heat loss. Could these be used in addition to black chrome to improve solar collector efficiency? Are there any solar collector manufacturers using such films in their collectors? - H.M., Bowie MD

Answer:

Low-transmission films such as Scotchtint™ were developed to block solar transmission through window glass into the building interior, avoiding un-wanted heat gain in some buildings. Low-transmission, heat reflecting films would not help solar collector efficiency.

The high-transmission, low-emissivity films such as Heat Mirror™ or 3-M's Sungain™ might boost solar collector efficiencies in some applications, particularly high-temperature collectors in cold climates. In this case, the added insulation value of the film might offset the transmission losses. The actual efficiency gains for the solar collector may still not justify the added expense.

As these products were developed for building glazings (windows), their durability in solar collector applications is in question. The effects of high temperatures, thermal cycling, and high UV exposure on the window glazing film had (in the 1980's) only been studied in a preliminary way. 3M informed us that its Sungain film will become brittle at temperatures above 250 degF., prohibiting its use in some solar collector applications.

While we know of no manufacturer using such films in their solar collectors, we have heard of some experiments in this direction.

Here we include solar energy, solar heating, solar hot water, and related building energy efficiency improvement articles reprinted/adapted/excerpted with permission from Solar Age Magazine - editor Steven Bliss.

Share this Article

...

Technical Reviewers & References

Search InspectAPedia

• Daniel Friedman - principal author/editor of the InspectAPedia^® Website
• InspectAPedia Bookstore lists recommended books, organized by topic & available for purchase. Most of our articles also include a list of recommended books for the specific article topic as well as other references, and information sources.
• Critique, contributions wanted: Contact Us to suggest corrections or additions to articles at this website, and if you wish, to receive online listing and credit as a contributor. Particular thanks are due to the many experts and also consumers who read and critique technical articles at InspectAPedia.com.
• Additional technical contributors & reference sources for this article are listed below.

Use links just below or at the left of each page to navigate this document or to view other topics at this website. Green links show where you are in our document or website.

AIR CONDITIONING & HEAT PUMP SYSTEMS
AIR BYPASS LEAKS
AIR LEAK DETECTION TOOLS
AIR LEAK MINIMIZATION
AIR POLLUTANTS, COMMON INDOOR
AIR SEALING STRATEGIES
ENERGY SAVINGS in BUILDINGS
ENERGY SAVINGS PRIORITIES
ENERGY SAVINGS RETROFIT CASE STUDY
ENERGY SAVINGS RETROFIT LEAK SEALING GUIDE
ENERGY SAVINGS RETROFIT OPTIONS
EVAPORATIVE COOLING SYSTEMS
EXTERIORS of BUILDINGS
FRAMING DETAILS for BETTER INSULATION
FRAMING DETAILS for DOUBLE WALL HOUSES
FREEZE-PROOF A BUILDING
HEAT LOSS CALCULATIONS
HEAT LOSS in BUILDINGS
HEAT LOSS DETECTION TOOLS
HEAT LOSS INDICATORS
HEAT LOSS R U & K VALUE CALCULATION
HOUSEWRAP AIR & VAPOR BARRIERS
HOUSEWRAP - TYVEK INSTALLATION DETAILS
HUMIDITY LEVEL TARGET
ICE DAM PREVENTION
INDOOR AIR QUALITY & HOUSE TIGHTNESS
INSULATION & VENTILATION INSPECTION & IMPROVEMENT
FOUNDATION CRACKS & DAMAGE GUIDE
HEATING SMALL LOADS
INDOOR AIR QUALITY & HOUSE TIGHTNESS
INSULATION & VENTILATION INSPECTION & IMPROVEMENT
INTERIORS of BUILDINGS
ACOUSTICAL SEALANTS
MOISTURE CONTROL in BUILDINGS
PLUMBING TOPICS
STRUCTURAL INSPECTIONS & DEFECTS
HEATING SYSTEMS
ROOFING
SHEATHING, FOIL FACED - VENTS
SOLAR ENERGY SYSTEMS
  PASSIVE SOLAR DESIGN METHOD
  PASSIVE SOLAR HEAT PERFORMANCE
  PHOTOVOLTAIC POWER SYSTEMS
  SLAB INSULATION, PASSIVE SOLAR
  SOLAR COLLECTOR AIR or GAS COLLECTION
  SOLAR COLLECTOR FILMS
  SOLAR COLLECTOR WOOD HOUSINGS
  SOLAR HEATING SYSTEMS
  SOLAR HOT WATER HEATERS
  SOLAR HOUSE EVALUATION
  SWIMMING POOL SOLAR HEAT, INDOOR
STRUCTURAL INSPECTIONS & DEFECTS
SUMP PUMPS GUIDE
THERMAL EXPANSION of MATERIALS
THERMAL MASS in BUILDINGS
THERMAL MASS in UPSTAIRS
THERMAL TRACKING Indicates Heat Loss
VAPOR BARRIERS & AIR SEALING at BAND JOISTS
VAPOR BARRIERS & CONDENSATION in BUILDINGS
VAPOR BARRIERS & HOUSEWRAP
VAPOR CONDENSATION & BUILDING SHEATHING
VENTILATION in BUILDINGS
WATER HEATERS
AGE of WATER HEATERS
ALTERNATIVE HOT WATER SOURCES
WATER SOFTENERS
WATER ENTRY in BUILDINGS
WIND TURBINES
WINDOWS & DOORS
  SKYLIGHT LEAK DIAGNOSIS & REPAIR
  SITE BUILT DOUBLE GLAZED WINDOWS
  SLOPED GLAZING DETAILS
  VERTICAL GLAZING DETAILS

• Solar Age Magazine was the official publication of the American Solar Energy Society. The contemporary solar energy magazine associated with the Society is Solar Today. "Established in 1954, the nonprofit American Solar Energy Society (ASES) is the nation's leading association of solar professionals & advocates. Our mission is to inspire an era of energy innovation and speed the transition to a sustainable energy economy. We advance education, research and policy. Leading for more than 50 years. ASES leads national efforts to increase the use of solar energy, energy efficiency and other sustainable technologies in the U.S. We publish the award-winning SOLAR TODAY magazine, organize and present the ASES National Solar Conference and lead the ASES National Solar Tour – the largest grassroots solar event in the world."

• Steven Bliss served as editorial director and co-publisher of The Journal of Light Construction for 16 years and previously as building technology editor for Progressive Builder and Solar Age magazines. He worked in the building trades as a carpenter and design/build contractor for more than ten years and holds a masters degree from the Harvard Graduate School of Education. Excerpts from his recent book, Best Practices Guide to Residential Construction, Wiley (November 18, 2005) ISBN-10: 0471648361, ISBN-13: 978-0471648369, appear throughout this website, with permission and courtesy of Wiley & Sons. Best Practices Guide is available from the publisher, J. Wiley & Sons, and also at Amazon.com.
  Excerpts with updates and annotations expanding the original Best Practices Guide text can be found in the online review and book summary at BEST CONSTRUCTION PRACTICES GUIDE and also at DECK & PORCH CONSTRUCTION, at INDOOR AIR QUALITY IMPROVEMENT GUIDE, and in other articles found at InspectAPedia.com such as HOUSEWRAP AIR & VAPOR BARRIERS, SOUND CONTROL in BUILDINGS, and other topics.
• Thanks to professional inspector Bob Cheney for the photo of a site-built rooftop solar collector.
