This article provides a Detailed Chimney Inspection Checklist for use when inspecting a building chimney from outdoors. Watch out: no checklist can be complete, and you should never rely only on a checklist to perform a building inspection. A checklist is useful to help avoid forgetting certain key steps, but it is always possible that other defects are present that are not on your checklist. Readers of this outdoor chimney inspection checklist should be sure to review the illustrated chimney defect and inspection procedures at Chimney Inspection Outdoors From Ground and also Chimney Inspection Outdoors at Rooftop.
These articles on chimneys and chimney safety provide detailed suggestions describing how to perform a thorough visual inspection of chimneys for safety and other defects. Chimney inspection methods and chimney repair methods are also discussed. As with most inspection and safety topics, this material may be incomplete.
Here is a chimney inspection checklist built from multiple contributors. Contact Us if you have corrections or additions for this chimney inspection checklist.
We list these observations in a order (not the only possible order) that might be followed by a visual inspection beginning outdoors and continuing indoors throughout the building, basement to attic, and including appliances or devices that vent through a chimney.
Outside Chimney Observations
Chimney movement: leaning, settling, bending, breaking, cracks, separation from the building, bad footing;
Chimney height: too short, inadequate clearance above roof;
Chimney leaks: water leaking into the chimney interior or structure, such as efflorescence, frost cracking, spalling
Chimney cap missing, chimney cap not draining; wrong type of cap for flue type or items being vented
Chimney crown cracked, damaged, missing, leaking, or not properly sloped to drain off of the chimney top; no drip edge over chimney sides
Chimney crown (or cap in some parlance) missing capillary break between top crown and masonry chimney body (frost damage)
Chimney flues, multiple, terminating at same height at chimney top - masonry chimneys
Chimney flues, multiple, terminating adjacent to one another at different heights - metal chimneys & flues
Chimney flue extender of metal, rusted, leaky, damaged
Chimney flue incomplete, not extending through entire chimney height
Chimney flues cracked, broken, spalled clay flue tile liners visible at chimney top or inside the flue
Chimney flue improperly constructed - masonry flue, concrete omitted or concrete extending into the flue between masonry tiles; expansion space not left between clay liner and masonry chimney
