Chimney Safety When Changing Fuels or Heating Appliances on a Masonry Flue InspectAPedia®  -     What to do about chimneys when you are changing fuel from oil to gas, gas to oil, coal to oil or gas, etc. Effects on chimney safety when switching from oil to gas, gas to oil, etc.

Changing fuel, for example from oil to gas, can present serious chimney safety hazards that need to be addressed by cleaning, inspection, and possibly repair or re-lining of the chimney flue.

These articles on chimneys and chimney safety provide detailed suggestions describing how to perform a thorough visual inspection of chimneys for safety and other defects. Chimney inspection methods and chimney repair methods are also discussed.

As with most inspection and safety topics, this material may be incomplete.

© Copyright 2012 InspectAPedia.com, All Rights Reserved. Information Accuracy & Bias Pledge is at below-left. Use page top links to major topics or use links at the left of each page to navigate within topics and documents at this website. Green links show where you are in a document series or at this website.

Changing Fuels or Heating Appliances on a Masonry Flue

Changing fuel, for example from oil to gas, can present serious chimney safety hazards that need to be addressed by cleaning, inspection, and possibly repair or re-lining of the chimney flue.

Masonry chimneys without flue tiles must be lined before a new appliance can be installed.

• Metal liners: Typically, a flexible stainless steel metal liner is inserted into the flue space and secured with various design techniques ranging from a cap plate at the top to pressure grouting between the masonry surround and the new liner.

  Good practice includes pouring an insulating material around the metal liner, between the liner and the interior of the chimney wall, and also a good chimney rain cap and top crown seal.
• Poured cement or a two step cement fill and ceramic glaze can be used. Processes such as SupaFlu™ or PermaFlu™ use a refractory cement that is poured into the chimney around an inflated central core.

  While these cements may be lightweight, nevertheless the chimney must be basically structurally sound for these processes to succeed.
  |
• Expert installers can sometimes salvage an old un-lined or damaged chimney by making the chimney liner pour in stages to reduce the chances of a chimney collapse.
