Death by electrocution touching high voltage wires - Rex Cauldwell to Daniel Friedman 2008Touching Electrical Equipment - Safety Hazards and Electrical Inspection Procedures
InspectAPedia®  -

  • Safety advice on touching electrical components

This article reviews safe and unsafe methods for touching or not-touching electrical equipment during its inspection. This is a sub-chapter of our article on electrical safety procedures which discusses safety hazards at residential electrical panels and suggests safety procedures for the electrical inspector, home inspector, or other professionals who examine residential electrical systems.

The gruesome death by electrocution shown in the photograph occurred when the man shown tried to steal electrical power from a high voltage cable. - Jim Simmons

Safe electrical inspection procedures and safe use of volt meters, DMMs, multimeters, and similar electrical test equipment is discussed at the end of the article. Original text: DF, as ASHI Technical Journal Staff, January 1992, with updates February 2006. © Copyright 2009 Daniel Friedman, All Rights Reserved. Information Accuracy & Bias Pledge is at below-left. Use links at the left of each page to navigate this document or to view other topics at this website. Green links show where you are in our document or website.

Our site offers impartial, unbiased advice without conflicts of interest. We will block advertisements which we discover or readers inform us are associated with bad business practices, false-advertising, or junk science. Our contact info is at InspectAPedia.com/appointment.htm.

Touching electrical equipment during an inspection

Never touch metal plumbing or gas system pipes while you're working around electricity. Never touch electrical equipment while standing on a damp or wet surface.

Open electrical panels are dangerous (C) Daniel FriedmanDuring an inspection an ASHI inspector warned the home owner that there was a short in a florescent ceiling light fixture. The owner, a contractor who had done his own electrical work, irritated and incredulous at this supposed defect, licked his knuckles and bridged a small space between the light body and a nearby gas pipe. He's now a believer. [NOTE: DJF home inspection, Beacon, NY 1990]

A very questionable procedure is suggested in The ASHI Training Manual [NOTE: "Electrical Systems," ASHI Training Manual, chapter by Alfred L. Alk, p. 18. ASHI 1987] indicating that the inspector can "test" to see if a panel is dangerously "live" (has an internal short) by tapping the box with the knuckles of his/her right hand to check for current, then laying the right palm on the box to feel for heat before beginning to remove the cover. Don't do this!

From a safety view, this is a bad idea. Never rely on physical touch to judge electrical safety of a component. Use instruments. Test instruments such as the VOM described above, and the TIFTM Tic Tracer shown at left are inexpensive, effective, safer when used properly. [NOTE: Alexandra Radkewycz, a Canadian researcher, reports severely shocking experiences from failure to make proper use of instruments. [Private communication to author, 12/91.]

Touching Electrical Equipment During an Inspection?

  • Never touch metal plumbing or gas system pipes while you're working around electricity.
  • Never touch electrical equipment while standing on a damp or wet surface. [Unless you are trained and are wearing appropriate protective gear.]

Shocked homeowner: During an inspection an ASHI inspector warned the home owner that there was a short in a florescent ceiling light fixture. The owner, a contractor who had done his own electrical work, irritated and incredulous at this supposed defect, licked his knuckles and bridged a small space between the light body and a nearby gas pipe. He's now a believer. [NOTE: DJF home inspection, Beacon, NY 1990]

Amazing Alk: A very questionable procedure is suggested in The ASHI Training Manual [ "Electrical Systems," ASHI Training Manual, chapter by Alfred L. Alk, p. 18. ASHI 1987] indicating that the inspector can "test" to see if a panel is dangerously "live" (has an internal short) by tapping the box with the knuckles of his/her right hand to check for current, then laying the right palm on the box to feel for heat before beginning to remove the cover. DO NOT RELY ON THESE UNSAFE METHODS.

From a safety view, this is a bad idea. Never rely on physical touch to judge electrical safety of a component.

Greenlee GT-16 adjustable voltage detector (C) Daniel Friedman

Use electrical test instruments to check for live voltage. Test instruments such as the VOM described above, and the TIFTM Tic Tracer (above), and the contact and "touchless" pens (photo at left) and tools used to detect the presence of voltage are inexpensive, effective, safer when used properly.

[Alexandra Radkewycz, a Canadian researcher, reports severely shocking experiences from failure to make proper use of instruments. Private communication to author, 12/91.]

See VOLTAGE MEASUREMENT EQUIPMENT for a description of tools used to detect the presence of live electrical wires & devices and for the measurement of actual volts or amps. See Using DMMs & VOMs Safely for details about using test equipment during an electrical inspection.

In the same ASHI Training Manual chapter the author, Al Alk, offers another more accepted suggestion: "Inspectors should practice working around open enclosures with the left hand behind the back. If the right hand receives a shock the current will more likely pass down the right half of the body: the heart is on the left side. Inspectors who wear rings must be especially wary when working near an open box." [NOTE: ASHI Training Manual, Op. Cit.- Obsolete]

Grounding: A basic rule for working around electrical equipment: if you are yourself not grounded, and if you only touch one single component at a time, risks are reduced. Never ground yourself through your feet. Don't stand on a wet floor. If it's necessary to touch electrical components in such a location, a trained electrical worker uses a dry ungrounded platform such as boards or a wooden ladder.

Rings and watches: When working around electrical equipment, first remove rings and watches to reduce the risk of electric shock. At an IBM test site in Poughkeepsie, NY in the 1980's a test technician was killed while working on a computer. His metal watch band contacted a live component while other body parts were touching a grounded component, possibly the steel frame of the assembly. Similar accidents around electric panels are a real risk for home inspectors.

Electric Panel cover screws: if you find that a sharp-tipped sheet metal screw has been used (usually to replace a lost original fastener) you should be alert for pierced, damaged, short-circuited wires in the panel - both during removal and during panel cover replacement. We will not reinstall a sharp-pointed screw in a panel cover if wires are crowded close to the screw opening. Having seen more than one shorted and burned panel from precisely this cause, we warn clients about this unsafe detail. It is trivial to correct.

Never Assume You've Turned Power Off - Use a Neon Tester, Voltage Detector, or Multimeter

Neon TesterThe most basic electrical safety procedure I can think of when working on electrical devices or electrical wiring involves knowing how to:

  • turn off power to the device or circuit or system where you're planning to work
  • make sure that power is really OFF there

I never touch something electrical that I've "turned off" without using at least a neon tester to or a voltage detection pen to see that electrical power is really off. In 1970 I turned off power to a junction box to fix a light - the light went out - so I figured that all electrical power to the junction box was really off. Then while wiggling wires in the junction box I got a huge spark and a little shock.

Some nitwit had run two different live circuits into the same junction box.

Now I'm more careful. I figure that if you don't electrocute yourself, the rest is easy - you can always run out of a burning building. Well really inspectors have more responsibility than that: in addition to not killing yourself, you must protect the safety of your clients and of the occupants of buildings on which you've performed work.

VOLTAGE by EQUIPMENT describes voltage sensors, DMMs, VOMs, and other choices of equipment we use for testing electrical circuits and for performing basic electrical or appliance wiring repairs.

General Electrical Safety Suggestions describes important basic safety procedures, clothing, and equipment for home inspectors and electrical inspectors.

Share this Article

...

Technical Reviewers & References

  • Daniel Friedman - principal author/editor of the InspectAPedia® Website
  • InspectAPedia Bookstore lists recommended books, organized by topic & available for purchase. Most of our articles also include a list of recommended books for the specific article topic as well as other references, and information sources.
  • Critique, contributions wanted: Contact Us to suggest corrections or additions to articles at this website, and if you wish, to receive online listing and credit as a contributor. Particular thanks are due to the many experts and also consumers who read and critique technical articles at InspectAPedia.com.
  • Additional technical contributors & reference sources for this article are listed below.

Use links just below or at the left of each page to navigate this document or to view other topics at this website. Green links show where you are in our document or website.

SAFETY: ELECTRICAL INSPECTION SAFETY
  Shock Risk Statistics
  Outside Electrical Inspection
  Electric Meter & Service Entry
  Local Electrical Grounding
  Electrical Panel Interior Inspection
  Removing Electric Panel Covers
  Electrical Panel Cover Screws
  Electrical Panel Interior Hazards
  Testing Main Breakers or Fuses
  Inspect Breakers, Fuses, Circuits
  Testing Receptacles GFCIs AFCIs
  When to Shut Down Equipment
  Touching Electrical Equipment
  Guide to Electrical Test Equipment
  Using DMMs & VOMs Safely
  Voltage Measurement & Detection
  General Electrical Safety Suggestions
  Electrical Inspection Client Safety

  • Electrical shock injury statistics: www.healthatoz.com - September 2008;

    High-tension current generally causes the most serious injuries, although fatal electrocutions may occur with household current (eg, 110 V in the United States and Canada and 220 V in Europe, Australia, and Asia). Contact with alternating current at 60 cycles per second (the frequency used in most US household and commercial sources of electricity) may cause tetanic skeletal muscle contractions, preventing self-release from the source of the electricity and thereby leading to prolonged exposure. The repetitive frequency of alternating current also increases the likelihood of current flow through the heart during the relative refractory period (the "vulnerable period") of the cardiac cycle. This exposure can precipitate ventricular fibrillation (VF), which is analogous to the R-on-T phenomenon.-- circ.ahajournals.org - September 2008

  • Thanks to Alan Carson and Bob Dunlop, Carson Dunlop, Associates, Toronto, for permission to use illustrations from their publication, The Illustrated Home which illustrates construction details and building components. Carson Dunlop provides home inspection education, publications, report writing materials, and home inspection services. Alan Carson is a past president of ASHI, the American Society of Home Inspectors.
  • "Frequency of Occurrence and Sources of Rust and Corrosion in Electrical Panels," Daniel Friedman, IEEE HOLM Conference, Philadelphia PA, 1992 - see ELECTRIC PANEL RUST for an online version of this article.
  • Jim Simmons: Personal communication, J. Simmons to Daniel Friedman, 9/19/2008. Photographs contributed to this website by Jim P. Simmons, Licensed Electrician, 360-705-4225 Mr. Electric, Licensed Master Electrician, Olympia, Washington Contact Jim P. Simmons, Licensed Master Electrician, Mr. Electric, 1320 Dayton Street SE
    Olympia, WA 98501, Ph 360-705-4225, Fx 360-705-0130 mrelectricoly@msn.com
  • Kenneth Kruger: Original author of the sidebar on testing VOM DMM condition: Kenneth Kruger, R.A., P.E. AIA ASCE, is an ASHI Member and ASHI Director in Cambridge, MA. He provided basis for this article penned by DJ Friedman.
  • "How to Use DMM's Safely," Leonard Ogden, CEE News, 888 Seventh Ave., New York, NY 10106, Dec 1990 p.10.
  • Dr. Jess Aronstein, consulting engineer, Poughkeepsie NY, 1991 protune@aol.com
  • Rex Cauldwell, master electrician and contributor to the Journal of Light Construction on electrical topics
  • New York State Central Hudson Gas and Electric Company, G&E/1-2/85 consumer safety pamphlet
  • American Society of Home Inspectors, ASHI Training Manual, Al Alk -[obsolete, and includes unsafe practices-DF]
  • Critique, contributions wanted: Contact Us to suggest text changes and additions and, if you wish, to receive online listing and credit for that contribution.
